RFID Box Station
RFID Box Station
RFID Box Station

RFID Box (RFKL-RU7)

Brand : RFgate
Discount Rate : %39 Discount
Price : $1,600.00  + VAT
Discounted : $979.00  + VAT

Rfid Box has the capacity to easily read large-sized parcels with its large upper reading area. It can read the products inside the parcels placed on it without opening the parcels, and it does this within seconds. It also gives you high performance and reliable results with an accuracy rate of over 99%. It carries your products safely thanks to its durable design created during the production phase and the high quality aluminum used in it. Its body is as light as it is durable. It has a USB/Network input on it, so you can connect it to the computer and perform your operations much faster.



Device Physical Features





Body Dimensions Length: 60cm Width: 45cm Height: 17cm
Reading Area Dimensions Length: 60cm Width: 40cm
Weight 8 kg.
Body Material Aluminum
Operating Temperature +10 ºC to +65 ºC
Nem 5% to 65%
Power Input 230v







RFID Reader Features





RFID Protocol GS1/EPCglobal UHF Gen2 (ISO 18000-6C)
Operating Frequency 865.6MHz - 867.6MHz (Optional)
Output Power +10.0 ~ +31.5 dBm
Max Receiving Sensitivity -84 dBm
Min Return Loss 10 dB
API LLRP, C, C++, Java, C# libraries
Network DHCP, Static
GPIO 4 Input - 4 Output
Intensive Reading Mode There is
Special Area Reading TID, User, Reserved




RFID Packet Antenna Specifications

Antenna Type Circular
Antenna Gain 5 dBi
Antenna Dimensions 38cm x 38cm x 1cm
Antenna Frequency 865MHz - 867MHz
Antenna Weight 1.116kg
Antenna Feed Type SMA

It is not suitable for direct use by end users without detailed technical knowledge and equipment.
